OPTICAL SYSTEM
Light source: 0.2W x 1584 pcs OSRAM 3 in 1 RGB LEDs
Lifespan: ≥ 50,000 Hours
EFFECT CONFIGURATION
The fixture is divided into 12 segments; all RGB in each segment can be controlled individually as pixel to create various graphic effects
Full range dimming, dimming accuracy 65536 levels, high brightness output
Strobe frequency: 1-25 Hz
Color macro and color gradient effect
Multiple strobe and graphic effect
MOVEMENT PARAMETER
Tilt: 182°Accuracy: 0.94°/ step Fine accuracy: 0.0037°
CONTROL AND PROGRAMMING
Control Channel: 7(Simplified)/19(Standard)/44(RGB pixie)
Protocol: DMX512
DMX: 3-pin XLR input/output (5-pin XLR for option)
Operation Mode: button control
DIMENSION AND WEIGHT
391mm × 152mm × 291mm
Net Weight: 11kg (fixture)
